Gold TOWNER A.BLOCK adaptor System for bisgby on FIREBIRD

TOWNER A.BLOCK System Designed for the Gibson FIREBIRD and Epiphone FIREBIRD guitar. • The TOWNER A.BLOCK provides a square surface to install the BIGSBY® on the asymmetrical guitar. • The TOWNER Down Tension Bar manages your sustain controlling your break angle.
• The TOWNER Down Tension Bar allows you to control how much string tension you want.           – Recommended to set the Down Tension Bar just below the saddles of the bridge.  The TOWNER Hinge Plate Adaptor is designed to provide a flat surface for your strap lock or strap button on the BIGSBY® EX-SHORT hinge plate.
The TOWNER Hinge Plate Adaptor slot provides room for exact placement of the BIGSBY®.
The TOWNER Hinge Plate Adaptor and 2″ strap button screw acts as a retainer holding the BIGSBY® to the guitar body, relieving you from having to drill four extra screws into your guitar.

*NOTE – CHECK WIDTH of STUD NECK POST:
Measure the neck width of your studs, they should be NO wider than 0.265 inches, if they are wider than 0.265 inches you will need to purchase different tailpiece mounting studs, likely . Gibson Memphis reissues and Gibson reissues sometimes have wider neck posts, measure to be sure. (*The TOWNER Down Tension Bar is designed to fit the neck width of stock GIBSON Guitar stud posts.)

• TOWNER A.BLOCK
• TOWNER Down Tension Bar
• TOWNER Hinge Plate Adaptor
• 2″ Strap Button Screw
• 4 1/2″ 2-56 Screws
• 4 Felt Pads
