Fender Stratocaster Loaded Pickguard CS Texas Specials/Blender

Brand new Start loaded pickguard with Custom Shop Texas Specials with Middle RP/RW, Treble Bleed Circuit and Blender Pot. These pickups are configured as follows. Tone Pot One is the Master Tone. Tone Pot Two is the No Load Blender Pot. There should be plenty of options to find your tone!

Full Clockwise = No Blend Full Counterclockwise = Full Blend
POS 1 Bridge - Add Neck with Blender POS 2 Middle & Bridge - Add Neck with Blender POS 3 Middle POS 4 Middle and Neck - Add Bridge with Blender POS 5 Neck - Add Bridge with Blender

The Treble Bleed Circuit

The treble bleed mod is a circuit which can help you keep the treble in the guitar signal, when you're turning down the volume potentiometer.

Probably you know, that when the volume pot knob is turned a little bit down, the guitar signal is quieter and also darker or smoother – it's losing some high frequencies. Treble bleed mod will help in preventing treble frequencies from bleeding to the ground.

The Blender Pot

The Blender wiring has 1 volume, 1 master tone, and a Blender pot. In the neck position you can blend the bridge pickup in as much as you want. In the bridge position you can blend the neck pickup in as much as you want. In positions 2 and 4 you can have all three pickups on." No extra switches or pots..



NOTE: If you always have tone and volume max out these circuits will have no effect, like a standard Strat. They only function when Volume is turned down, Treble Bleed. Tone is turned down, Grease Bucket or when the Blender pot is moved from zero position.
