RH Factor Hendrix Inspired Pickups Loaded Pickguard with Premium Electronics!

This is a quality built prewired Stratocaster Loaded Pickguard. We started off with a custom WD Pickguard for a Jimi Hendrix Voodoo Stratocaster. Then we loaded it with our own RH Factor Hendrix inspired Pickups, Premium CRL 5 way switch, Mojotone vintage CTS 250K pots, Taihan Black Bee .047uF oil filled Cap, Pure Tone Jack and wired it up with Gavitt pre-tinned cloth wire. Also included is an Allparts knob and switch tip kit. This is the perfect pickguard for your Jimi inspired Voodoo Stratocaster!

Note:  If you would like a treble bleed ckt installed we can add one for an additional $5.00.

We can accommodate any cap shown in the last picture from Sozo, Russian PIO, WD PIO Black Beauty, MoJoTone Dijon film/foil, MoJoTone Vitamin T PIO, Mallory Mustard Caps and Orange Drop. I can get other caps if there is something special you want. We also have Oak Grigsby Switches.

We have other parts in stock if you want us to put together a complete guitar kit. We have tremolos, tuners, string trees, and neck plates with or without a serial number. Call us at 740-405-9509 to discuss options.

  • WD Music Custom Voodoo Strat 3 Ply W/B/W Pickguard (Note this will require a reverse bridge pickup or humbucker route) We can also do this setup in a standard Strat pickguard.
  • RH Factor Hendrix Inspired Pickups Measurements: Neck and Mid 5.8K and Bridge 6.3K approx. Actual measurements are written on the back of the pickups.
  • MojoTone Vintage 250K CTS Pots  30% Taper, 7% Tolerance with the lowest torque! (Matching Set)
  • Taihan Black Bee .047uF Oil Filled Cap
  • CRL 5 Way Switch
  • Pure Tone Jack (Dual Tension Grounds and Dual Positive Tips for better connection)
  • Gavitt Pre-Tinned Vintage Cloth Wire (If you need extra wire we can add it for .60 cents a foot)
  • Allparts White Knob and Switch Tip Set
RH Factor Hendrix Strat Pickup set plays clean with a tight bass for that special Jimi vibe! These are quality pickups made from AlNiCo 5 magnets, grey fibre bottom flat work, enamel coted wire and cloth connecting wire. Search Google and Youtube for RH Factor Pickups. You will not be disappointed.

All pickguards are bench checked before packing them up.

Please Note: When you receive this pickguard, please examine it before doing and work on it. If you have any concerns please get in touch with us. We will not except any returns once it has been modified in any form.

Take a look at all the pictures and ask all questions before buying. This part will be packaged securely before shipping.


ConditionBrand New (New)
Brand New items are sold by an authorized dealer or original builder and include all original packaging.Learn more
  • Hendrix Loaded Pickguard
  • White / Black / White
Made In
  • United States
