Product Specifications:
- Speaker Type: 2-Way Active Speaker
Acoustical Data
- Frequency Response [-10dB]: 49 - 20.000 Hz
- Frequency Response [+/- 3dB]: 58 - 19.000 Hz
- Max SPL: 129 dB
- HF: 1"
- Type HF: Compression driver
- Voice Coil HF: 1.4"
- Directivity: 80/65 x 60°
- Horn: Asymmetrical CD Horn
- LF: 15"
- Voice Coil LF: 2"
Amplifier
- Amp Technology: digipro
- Amp Class: Class D
- Power PRG: 600 W
- HF Amp: 100 W/RMS
- LF Amp: 300 W/RMS
- Cooling: Convection
Processor
- Controller: DSP / 24bit/48kHz
- System Presets: Flat / Processed
- Limiter: Dual Active / Peak, RMS, thermal
- Delay Option: No
- Crossover Frequency MF-HF: 1940 Hz
- Slope MF-HF: 24 dB/Octave
Input Section
- Signal Input: 1x XLR / 1x 6.3mm phone jack
- Microphone Input: Yes
- Signal Output: 1x XLR / 1x 6.3mm phone jack
- Power Socket: VDE
- Voltage Range: 240 V
Mechanics
- Housing: PP
- Housing Design: Multifunctional
- Color: Black
- Handles: 1x on top / 2x side
- Pole Mount: 36mm
- Angles Up: Monitor use 43°
- Front Grille: Metall, 1.2mm with acoustical foam
- Width: 432 mm (17.28 in)
- Height: 655 mm (26.2 in)
- Depth: 353 mm (14.12 in)
- Weight: 14.5 kg (31.09 lbs)
