Synthrotek MST VC LFO (Eurorack Module - 10)

$110
+ $7 Shipping
$2 shipping when combined
As low as $10/month with
This seller is open to offers
Shipped From
Rad Scientist
Nashville, TN, United States
(2)
Joined Reverb
2021

Reverb Protection

Simple Returns, Secure Transactions, Human Support

Secure Checkout

At Reverb, your safety and security is our priority.

I build all of my listed modules myself.  If you have any issues with your module, please contact me and not the brand of the module.  I will help you get sorted.

THESE USE 16 to 16 PIN IDC CABLES, NOT 16 to 10

Built and never placed in a rack.

MST Voltage Controlled Low Frequency Oscillator is another tiny, useful module packed to the gills with features. Manual and CV control over rate with 3 discrete waveform outputs.  A square wave can be used to clock modules such as our Noise, Sample & Hold module. Great for creating vibrato, tremolo or other classic modulation techniques.  Great for frequency modulation, especially when connected to the MST analog VCO.

Features:

Voltage Control rate input with attenuator control

Manual rate control

Slew/Symmetry control

Positive and negative LED indicators

Square, triangle and sine wave outputs

Specifications:

Manual range: Approx 51 Second to Approx 102 Hz

Time with Max range, +5V CV: 1,450Hz

Time with Max range, -5V CV: 1 Hz

Time with Min range, +5V CV: 2 Hz

Time with Min range, -5V CV:  1.5 Hours

Skew range, all waveforms: 14% to 86%

Current draw: V+ max 11.75mA, V- max 12.2mA

Width: 4HP, Depth: 4.77 cm (1.88 in)
