Great sounding Neve style EQ
2nd unit available. check my listings
From Sound Skulptor:
The EQ573 is an parametric equalizer based on the design that was originally used in the Neve 1073 and 1084 modules, that has been adapted to the '500' format of API*.
The EQ573 can be used as a standalone unit but also as an insert, between the input and output stages of the MP573 mic pre, recreating the full architecture of the 1073.
Just install it in your API* compatible LunchboxTM rack and start recording.
Highlights
• Three bands equalizer and high pass filter
• High shelf EQ: +/-16dB @ 10kHz, 12kHz, 18kHz, 20kHz, 25kHz
• Mid EQ: +/-18dB @ 0.27kHz, 0.36kHz, 0.5kHz, 0.7kHz, 1.1kHz, 1.6kHz, 2.3kHz, 3.2kHz, 4.8kHz, 7.2kHz, 10kHz
• Low shelf EQ: +/-16dB @ 20Hz, 35Hz, 60Hz, 110Hz, 220Hz
• High pass filter: -18dB/octave @ 25Hz, 45Hz, 70Hz, 160Hz, 360Hz
• Additional frequencies in all bands
• 3 Q values for the mid EQ (1073, 1084 and 1084-Hi)
• Pre/Bypass/XLR switch on the front panel allows both MP573 insert or standalone mode
• Single ended, class A circuit
• Carnhill inductors
2nd unit available. check my listings
From Sound Skulptor:
The EQ573 is an parametric equalizer based on the design that was originally used in the Neve 1073 and 1084 modules, that has been adapted to the '500' format of API*.
The EQ573 can be used as a standalone unit but also as an insert, between the input and output stages of the MP573 mic pre, recreating the full architecture of the 1073.
Just install it in your API* compatible LunchboxTM rack and start recording.
Highlights
• Three bands equalizer and high pass filter
• High shelf EQ: +/-16dB @ 10kHz, 12kHz, 18kHz, 20kHz, 25kHz
• Mid EQ: +/-18dB @ 0.27kHz, 0.36kHz, 0.5kHz, 0.7kHz, 1.1kHz, 1.6kHz, 2.3kHz, 3.2kHz, 4.8kHz, 7.2kHz, 10kHz
• Low shelf EQ: +/-16dB @ 20Hz, 35Hz, 60Hz, 110Hz, 220Hz
• High pass filter: -18dB/octave @ 25Hz, 45Hz, 70Hz, 160Hz, 360Hz
• Additional frequencies in all bands
• 3 Q values for the mid EQ (1073, 1084 and 1084-Hi)
• Pre/Bypass/XLR switch on the front panel allows both MP573 insert or standalone mode
• Single ended, class A circuit
• Carnhill inductors
