Yamaha MTX3

The Yamaha MTX3 is a 26 x8 matrix mixer with signal processor with an 8-channel mic/line input and 8-channel analog output, 16-channel YDIF digital I/O and SD card slot for playback. Designed primarily for multi-zone commercial installations, MTX Series matrix processors are equipped with flexible processing functions that are essential to a wide variety of applications such as retail stores, restaurant/bars or banquet rooms. Responsible for the primary processing functions at the heart of your system's design, MTX processors allow you to configure, program, and manage your entire sound solution via the intuitive interface of the accompanying MTX Editor software application. The series is comprised of two models with varying DSP capacities and expansion capabilities, allowing MTX processors to meet the demands of a truly impressive range of commercial environments.

From a customer perspective, the ability to access simple control of their audio system is crucial, no matter how sophisticated that system is. For this reason, Yamaha provides a wide range of remote control options. These include simple DCP wall panels with wireless equivalents that can operate from an iOS or Android phone or tablet. Then, there is more sophisticated MCP1 programmable wall mount controller, PGM1 advanced paging station microphone and the fully customizable ProVisionare Touch and ProVisionaire Control Apps for iOS tablets and Windows devices respectively. The MTX Series feature an input/output configuration that is ideal for a wide range of applications: 8 mono inputs (mic/line), 2 stereo inputs (line) and 16 digital inputs via YDIF. The output side consists of 8 line-level mono outputs and 16 digital outputs via YDIF. MTX processors also feature an SD Card Slot for playback of MP3/WAV files stored on an SD Memory Card. The Event Scheduler function allows you to play back these files as music, announcements or chimes—or even trigger external devices with a GPI output—at scheduled times, as well as recall presets stored within the MTX.

Features

Memory bank: PRESET: 50

Mixing Capacity: Mixing Channel : 8 Mono + 3 Stereo + 2 Effect Return + 8 Insert

Output Busses: 8 Mono

Input Channel Functions: Mono CH : 3-band PEQ, Comp, Gate, Auto Gain Control, Feedback suppressor (only available in ch 1-4)

Stereo CH: 3-band PEQ, Comp, Auto Gain Control

Specifications

Output Channel Functions: Room Delay, Room EQ, Speaker Processor, X-Over (1-way, 2-way), Delay, 6-band PEQ, Limiter

Internal Processing: Priority Ducking, Ambient Noise Compensator

Sampling frequency rate: 48kHz

Signal delay: Less than 2.5ms (AD-DA @48kHz)

Total harmonic distortion: Less than 0.05% (+4dBu, Gain:-6dB), Less than 0.1% (+4dBu, Gain:+66dB)

Frequency response: 20Hz to 20kHz, +0.5dB, -1.5dB

Dynamic range: 107dB (Gain:-6dB)

Hum & noise level: (20Hz to 20kHz), Rs=150 Ohms

Phantom Power: +48V

Crosstalk (@1kHz): -100dB

Heat diffusion: 43kcal/h max

Power requirements: AC100V-240V 50Hz/60Hz

Power consumption: 50W

Dimensions: 18.9" W x 1.7" H x 14.3" D

Weight: 10.6 lbs
