Beat - Drum Machine / Dedalo

Dedalo Fx

beat
drum machine

Create your own drum beats.
This pedal is a programmable drum machine, where you can easily make your own beats to play along. You can connect it to your effects chain, or use it separately on a synched electronic set.
Made entirely on uController technology, and boasting 8-bit samples from our vinyl record collection, this machine will led you to create interesting rhythmic patterns and bring a new air to your music.

Features
Digital drum machine with 32-step sequencer
Specially crafted 8-bit sounds sampled from vinyl
Guitar level input
Foot control for live use
SYNC and MIDI connections for syncing with other instruments or DAWs
Pitch-Down and Aliasing effects
Additional Joystick and Mash-up modes

Synchronization

MIDI:
MIDI input/output with TRS conector (Type A Standard)
Receives and sends MIDI Clock/Transport
Receives and sends Program Change
Receives and sends Note ON
MIDI THRU option

CLOCK:
IN/OUT conections on TRS conector (not at the same time)
Standards 1PPS (Korg, etc) and 24PPQ (Arturia, Roland etc) with various options
Receives and sends Clock and Start/Stop signals

All functions are set from within the pedal

Sampling rate: 31.250Khz
Bit depth: 8bits
Storage medium: EEPROM memory (internal)
Input impedace: 700Kohm
Output level: instrument level (nominal)
Powered by standard 9v DC Adapter (not included)
