DiMarzio DP193BC Air Norton Neck and DP155BC Tone Zone Bridge Humbucker Set, Black and Creme, with Ernie Ball EB2220 Power Slinky Strings

The Air Norton started out simply to be the Airbucker version of the Norton. DiMarzio thought it would make a distinctive-sounding bridge pickup with high-gain amps, but they soon discovered that itﾒs a radically neat neck pickup, too. The tone is deep and warm, but not muddy. Itﾒs hot, but not distorted. Itﾒs even got cool harmonics, which are really unusual for a neck humbucker. The patented Air Norton magnetic structure reduces string-pull, so sustain is improved; and pick attack and dynamics are tremendously controllable and expressive. Combine the Air Norton with an Air Zone, The Tone Zone or Steveﾒs Special in the bridge position for a perfect blend of power and tone, or use an Air Norton in the bridge position with an Air Classic Bridge model in the neck position for a distinctive medium-output blues-rock sound.

Recommended For Solid body and semi-hollow body guitars.

When the Air Norton is in the neck position, it's a warm, open-sounding pickup with enough power to balance with all bridge humbuckers. Try it with 500K pots for maximum treble and harmonic presence. In the bridge position, the sound is medium output with solid lows and biting harmonics. You can try it here with 250K controls, or a 500 K volume and 250K tone to fatten the highs up a little. Combines well with Air Classic in neck, and also with The Cruiser, The Chopper, and Blue Velvet single-coils.

Specs

• Wiring: 4 Conductor
• Magnet: Alnico 5
• Output mV: 270
• DC Resistance: 12.58 Kohm
• Year of Introduction: 1995
• Patent: 4,501,185 & 5,399,802

Have you ever heard a bridge pickup that made a guitar sound like a giant mosquito attack? If you’ve run into this problem, The Tone Zone is the solution. The Tone Zone is hot enough to qualify as a high-output pickup, but it has a wider dynamic range — hard picking will produce a lot of power, and softer picking will be much cleaner and quieter. It’s got tremendous bass and low-mid response to reinforce the bottom end and make the overall sound bigger. The highest single notes have depth, and chords sound huge. Patented dual-resonance coils reproduce more overtones than you’d expect from such a fat-sounding pickup. It makes a great match with an Air Norton, PAF Joe, or PAF Pro, and split-coil mode produces an excellent single-coil sound as well.


Specifications
Wiring: 4 Conductor
Magnet: Alnico 5
Output mV: 375
DC Resistance: 17.31 Kohm
