MULTI TIMBRE ELECTRIC GUITAR DESIGN (New Technology)
This guitar has extensively toured with guitarist Mike Keneally as part of his guitar arsenal with the Zappa Band. Mike has also recorded several new original compositions and used the AS guitar for contract work as well.
What would an electric guitar sound like if there was a way to produce two pure resonate voices and blend them into one guitars voice?
Shimmer, shimmer, shimmer! (See attached video...)
THE KEY IS IN THE ALTERED STATES 3D BRIDGE AND DUAL WOOD BODY DESIGN!
This AS guitar is the first of a series.
Built by master guitar builder Joe Donahue for Altered States Guitar Co.
GUITAR SPECIFICATIONS:
SCALE - 25.5"
BODY - Upper bout: Mahogany
BODY - Lower bout: Swamp Ash
NECK - Reverse cut lamination: Roasted Maple/Mahogany center stripe
TRUSS - Dual action
FRET BOARD - Ebony
FRET BOARD RADIUS - Compound 10" to 12"
NECK SHAPE - C shape at the nut to a soft V at heal
NUT WIDTH - 1 11/16" (Bone)
AS BRIDGE - Altered States split fixed 3D: String through body
HEAD STOCK - AS custom 3 on a side (Hip Shot locking)
PICKUPS - 2ea Fred Stuart low impedance humbuckers with split
FINISH - Natural hand oiled
TUNERS - Hip Shot locking
ELECTRONICS - 2 volume/push pull (CTS) & 2 tone (Bourns)
SWITCH - 3 way - 33uf
INLAY - Abalone
