For Sale is ONE
Ashly PQX 571, Seven Band Parametric Equalizer
Ashly PQX-571 Equalizer
The Ashly PQX Series equalizers are a third generation design including many refinements on the original PQ models. Lower noise, greater headroom, additional filters, full 20Hz -20KHz range on all parametric filters, and additional connector types are the result.
The heart of the PQX equalizers is a unique bandpass filter circuit. Basically a "state-variable" type, this filter is trimmed and optimized to provide excellent transient response and a wide range of frequency and bandwidth adjustment. Each filter can be tuned over a 100:1 frequency range (about 6.6 octaves) and a 70:1 bandwidth range with no more than a 2 dB amplitude error at center frequency. At its sharpest setting, the filter has a "Q" of about 35 and generates a response curve with 3 dB points only 1/20 octave apart, making feedback control possible with no audible side effects. Each filter is placed in the feedback loop of a summing amplifier to produce the desired frequency response. Since a separate summing amplifier is used for each band, no interaction between bands occurs.
After twenty years of refinement, the Ashly parametrics are the most powerful equalization tool available. They especially excel in control of resonance and feedback yet also provide smoother broadband tone shaping than Graphic equalizers.
Features
5 parametric and 2 shelving bands per channel.
Wide range adjustment of all parameters for powerful control.
Very low noise and distortion.
Condition description
- Used but in Great Condition and Great 100% Good working order
- This Sale is for one unit
- Fully Tested and is in 100% Good working order
Shipping Info
Shipping & Handling is $FREE.00 in the 48 Lower States.
This Does not include AK ,HI, PR , and Virgin Islands & But we have Great Shipping Rates to Those States/ Territory's
Great International Shipping Rates Also Available.
