neumann tlm 102

Brand New
$759.23
+$63.27Shipping
Watch this listing to get price drop alerts
Shipped From
Music Village
Mantova, Italy
68
Sales
100+
Joined Reverb
2019
Preferred Seller
Reverb Protection

Buy with Confidence – Reverb Protection has you covered

  • Live support from an expert team of musicians
  • Simple and straightforward returns
  • A safe community for finding the gear you want

About This Listing

MICROFONO A CONDENSATORE CARDIOIDE A CAPSULA LARGA

Il microfono TLM 102 a condensatore con diaframma largo definisce una nuova generazione di prodotti da studio firmati da Neumann. Nato espressamente per riprodurre la voce cantata, il parlato e tutte le applicazioni in ambito broadcast si propone come ideale sistema di ripresa anche dei suoni provenienti da strumenti particolarmente dinamici, dal sound aggressivo e generoso, come le percussioni, la batteria, gli strumenti a fiato e quelli amplificati. Dal punto di vista tecnico il TLM 102 è un microfono a condensatore con diaframma largo, con diagramma polare cardioide, direzionale, trasduttore a gradiente di pressione, di dimensioni compatte - inferiori rispetto al fratello TLM 103 - ma dalle classiche caratteristiche Neumann. La capacità di sopportare grandi pressioni sonore massime si accompagna a una leggera enfasi sopra i 6kHz e all'impiego di una tecnologia che evita l'impiego di trasformatori.
Specifiche tecniche
Trasduttore: Gradiente di pressione
Direttività: Cardioide
Circuito di uscita: Senza trasformatore
Banda passante: 20Hz - 20kHz
Sensibilità: 21 mV/Pa
Rumore: 12 dBA, 21 dB CCIR
Rapporto S/N: 82 dBA, 73 dB CCIR
SPL max: 144dB con THD <0,5%
Impedenza nominale: 50 Ohm
Impedenza nominale di carico: 1000 Ohm
Voltaggio di uscita massimo: 13dBu
Tensione di alimentazione: 48V ± 4V
Assorbimento: 3,5mA
Connettore: XLR-3 F
Colore: Argentato
Supporto orientabile SG2 incluso
Dimensioni: D52mm x 116mm
Peso: 0,260kg
-----------
CONDENSER MICROPHONE CAPSULE CARDIOID WIDE

The TLM 102 condenser microphone with large diaphragm defines a new generation of products to study signed by Neumann. Born specifically to play the singing voice, speech and all for broadcast applications provides an ideal camera system also sounds coming from particularly dynamic tools, aggressive and generous sound like percussion, drums, wind instruments and those amplified. From the technical point of view the TLM 102 is a condenser microphone with large diaphragm, with cardioid polar pattern, directional, pressure gradient transducer, compact dimensions - lower than the brother TLM 103 - but from the classic Neumann characteristics. The ability to withstand large maximum sound pressure is accompanied by a slight emphasis above 6kHz and the use of a technology that avoids the use of transformers.
Technical specifications
Transducer: Pressure Gradient
Pattern: Cardioid
Output circuit: Without transformer
Bandwidth: 20Hz - 20kHz
Sensitivity: 21 mV / Pa
Noise: 12 dBA, 21 dB CCIR
S / N Ratio: 82 dBA, 73 dB CCIR
Max SPL: 144dB THD <0.5%
Nominal Impedance: 50 Ohm
Rated load impedance: 1000 Ohm
Maximum output voltage: 13dBu
Supply voltage: 48V ± 4V
Consumption: 3.5mA
Connector: XLR-3F
Color: Silver
SG2 including swivel support
Size: D52mm x 116mm
Weight: 0,260kg
