ZYLIA PRO Have it all!

ZYLIA PRO Have it all! Set

3rd order Ambisonics microphone array for ambient and studio recordings

ZYLIA PRO gives you all the power you need for 3D audio recording. You can capture the whole 360˚ audio scene in the way you hear it in the real world with a high spatial resolution provided by 3rd order Ambisonics microphone array. In specialized software you gain more control over recorded audio, you can select sound pieces in post-processing and apply them in your VR/AR or game audio design work-flow.

ZYLIA PRO Set consists of ZM-1 3rd order Ambisonics microphone array and bundle of software - ZYLIA Studio, ZYLIA Studio PRO, and ZYLIA Ambisonics Converter and ZYLIA Studio Ambisonics Converter plugin.

Benefits:

• 3rd order Ambisonics microphone

ZYLIA PRO gives you all the power you need for 3D audio recording. Capture the whole 360˚ audio scene in the way you hear it in the real world. Create immersive 360 degrees sound scenes for your 360/VR/AR projects in Higher Order Ambisonics (HOA) format. According to our customers, the spatial resolution of ZM-1 is brilliant.

• Unlimited post-processing possibilities

Manipulation of 'Virtual Microphones' polar patterns and positions gives you the ultimate control over the recorded sound-field in post-processing. Change and test multiple microphone setups whenever you want.

• Surround presets

Easily map the recorded scene to several surround standards (binaural, 5.1, 7.1, 5.4.1, 22.2 and more) with one click.

• Mobility and ease of use

Take it outdoors to capture the unique ambience and sound effects for movies and games. Just plug ZM-1 with USB to your laptop or Windows tablet and you are ready to record.

Features:

ZYLIA ZM-1 microphone array

• High-quality recording with 48 kHz sample rate and 24-bit resolution

• Genuine representation of acoustic space

• 19 high-quality digital MEMS sensors distributed on a sphere

• LED ring status indicator informing about recording status

• USB connectivity making the process of recording easy

• Recording - ZYLIA Studio software or any DAW (Digital Audio Workstation)

Technical parameters:

General

• Number of microphones: 19 digital MEMS sensors
• Dimensions (including stand): height - 155 mm (6.1’’), length - 103 mm (4’’), weight - 470 g (16.6 ounces)
• Connection with computer: USB 2.0 (type A) to microUSB 2.0 (type B)
• Supply voltage: 5 V DC
• Current and/or power: max. 0.5 A 2.5 W, 0,15 – 0,26 A (+/- 0,01 A)

Microphones specification

• Frequency range: 20 – 20 000 Hz
• Dynamic range: 105 dB
• Signal to noise ratio (SNR): 69 dB(A)
• Total harmonic distortions (THD): <1% up to 128dB SPL
• Acoustic overload point: 130 dB SPL
• Directivity: omnidirectional
• Noise floor: -105 dB FS(A)

A/D conversion

• Sample rate: 48 kHz
• Bit resolution: 24-bit

ZYLIA Studio software

• Desktop application for MAC, Linux, and Windows (also Windows tablets)

• Record, mix, and store your recordings

• Extract individual instruments into separate tracks

• Create a balanced recording by adjusting the volume and panning of individual instruments or leave it for AUTOMIX option

• Multiple export possibilities (raw 19-channel recording, stereo mix, single instruments tracks) - polish your recording in your favorite DAW

• Free software updates

ZYLIA Studio PRO plugin

• Possibility to set and monitor virtual microphones of multiple polar patterns or characteristics - live or during post-production!

• Presets for surround standards such as 5.1, 7.1, 5.4.1, 22.2, and more.

• Sound sources separation in real-time

• Automatic detection of the sound sources positions

ZYLIA Ambisonics Converter software & ZYLIA Ambisonics Converter plugin

•     B-format conversion (1st, 2nd and 3rd order of HOA)

•     FuMa or ACN channel ordering & SN3D or N3D normalization

•     Compatible with ambiX

•   Support for YouTube360 and Facebook360

•   Correction of ZYLIA ZM-1 microphone position in the post-production stage

Plugin:

•   Available as VST, VST3, AU, and AAX* plugins

•   macOS and Windows versions

•   Compatible with DAW that supports at least 19 channels per track
