Quilter Panoptigon: Optical Disc Player, 3 Discs Incl. [Compatible with Orchestron and Optigan Disc]

STARTER DISC SET INCLUDED.  Each Panoptigon will come with Singing Rhythm, Oscillations, and the Orchestron Vocal Choir included.

The Panoptigon represents the culmination of years of research and development that carries an awesome vintage instrument into the modern era. Redesigned from the ground up, the Panoptigon empowers the artist with MIDI, modern effects, and a deeper and more thorough feature set than ever dreamed of before.

The original Optigan program discs came in many popular styles, and our new disc mastering system has enabled us to create and release never-issued discs from the master tapes rescued and preserved by Pea Hicks. In addition, we have mastered original discs, some of which go much further in exploiting the cyclical nature of the playback loop, resulting in loop libraries with endlessly entertaining combinations.


Maximum Polyphony:
60 Voices (Tracks) Current Draw:650 mA , 24V

Dimensions (W x D x H):17.6" (447 mm) x 16.75" (425 mm) x 5.25 (133 mm) without cover
17.6" (447 mm) x 16.75" (425 mm) x 5.50 (140 mm) with cover

Weight:13.4 lbs. (6.08 kg) without cover
15.1 lbs. (6.85 kg) with cover

Accessories:Dust cover, PS24 Power Supply, AC Cord, Disc Starter Pack, Owner's Manual

Connectors:MIDI (IN, THRU)
Headphones (3.5mm)
Audio Output x 2 (1/4" phone): LEFT-MONO SUM, RIGHT-TRS STEREO
Output Impedance: 1 kOhm
24 VDC Power (5.5mm barrel, 2.5mm pin, tip positive)
SYNC IN (3.5mm), SYNC OUT (3.5mm)

Power SupplyPS-24 (24 VDC, 3A)
