The Soultone 45ME3 HD-MILSPEC boutique amplifier is a Class-A/B, all-tube, 30 Watt, two-channel head, with a sophisticated variable power supply derived from the London Power Scaling system. It is a fantastic sounding JTM45 clone, with expanded versatility and is very home player friendly. This amp is serial # 016. Cosmetic condition is about 9.5 out of 10.0. No nicks, tears, or scrapes. Tolex and plates are in nice condition all around. Operationally, the amp is fantastic. It has has been checked out and is ready to go. The tube set are 4 vintage RFT ECC83 in the pre amp, power tubes are 2 new octal Gold Lion KT66, and a vintage Mullard GZ34/5AR4 rectifier. Here is a description of the amp from Soultone:
Vintage Plexi sounds with Variable Power! This is the most authentic yet flexible JTM45 style amplifier made! With switchable negative feedback taps, channel bridging and plexi/jtm tone modeling, the Forty-Five is an incredibly versatile amp, covering a range of British sounding amplifiers from the Sixties, Seventies, and Eighties, at volumes manageable from stage to bedroom levels.
FORMAT Smallbox sized head (26″x8.5″x9″).
POWER Variable to 45 Watts (actual maximum output based upon tube selection and OT)
TUBE COMPLIMENT 2 Octals: KT66, EL34, 6550, 6L6, 5881, 6V6GT match or mix them up and run with asymmetric configuration allowed!
RECTIFIER Contains a GZ34 tube and a built in Solid State FRED rectifier, with on the fly front panel selection.
COMPONENTS:
o Capacitors: Sozo Mullard replacements, Sprague Atom electrolytics, TESLA multicapcan
o Resistors: NOS Allen Bradley carbon-comp in tone path, wirewound, carbon and metal film for noise reduction.
o Potentiometers: Clarostat, PEC, and NTE – RV4 or better rating, all plastic-conductive
o Wire: Silver plated MILSPEC (rated for aircraft control signal wire),
o Sockets: NOS Micalex tube sockets
TRANSFORMERS Our exclusive ME3 transformer set, built to exacting specifications by Mercury Magnetics.
CONTROLS:
o Controls: Bass (pull Fat), Middle, Treble, Volume 1 (pull Bright), Volume 2 (Pull Feature – Channel Bridging Switch)
o Negative Feedback: selectable 16 ohm tap at 27K, or 8 ohm tap at 43K
o Power Scaling: Variable Power control, and Master limit controls
o Mode Switch: JTM45 or Plexi tone shaping
o Bias: Individual power tube bias with external rear test points and adjustment!
o All tube FX loop: Send level, Return level, True Bypass
CABINETRY 13 Ply voidless Baltic-birch.
