Recommended for vented professional audio enclosures for full-range or as mids.
- Nominal Diameter: 12", 305.0mm
- Nominal Impedance: 8 ohms
- Power: 400w rms, 800w program
- Freq. Response: 51.0 Hz-3.5 kHz
- Sensitivity: 100.5 db 1w/1m
- Magnet Weight: 11.0 oz, 312.0 grams
- Gap Height 0.365", 9.27mm
- Voice Coil Diameter 3.0", 76.2mm
- Recommended Enclosure Volume - Sealed: 28.0-76.0 L, 1.0-2.7 cuft - Vented: 41.0-110.0 L, 1.5-3.9 cuft
- Overall Diameter: 12.38", 314.45mm
- Baffle Hole Diameter: 11.06", 280.9mm
- Number of Mounting Holes: 8
- Mounting Hole Diameter: 0.28", 7.1mm
- Mounting Hole BCD: 11.62", 295.2mm
- Depth: 5.63", 143.0mm
- Net Weight: 7.1 lbs, 3.22 kg
- Shipping Weight: 8.7 lbs, 3.95 kg
This item is sold As-Described
This item is sold As-Described and cannot be returned unless it arrives in a condition different from how it was described or photographed. Items must be returned in original, as-shipped condition with all original packaging.Learn More.
| Condition | Brand New (New) Brand New items are sold by an authorized dealer or original builder and include all original packaging.Learn more |
|---|---|
| Brand | |
| Model |
|
