High efficiency Class D amplifier produces 30W RMS audio output (maximum music output 50W)
All-In-One! Easy to operate in both indoors and outdoors.
Rechargeable Lead-Acid battery eliminates all cables so you can take it anywhere!
Smart charging circuit with LED indicator.
Speaker system: 6 1/2" full range.
Up to 4 diversity receiver modules with 100/16 selectable frequencies in each system (optional).
Anti-interference Pilotone circuitry provides superior wireless reception.
Audio inputs: Mic in, Aux in
Audio outputs: Aux out, External speaker
Individual volume control for Mic in, Aux in, Bass, Treble.
Individual volume/power control for wireless microphone (WR1 & WR2)
Optional device: CD/USB player, Digital video player/USB/SD player, receiver/transmitter/Bluetooth receiver/Digital music player with recorder.
The CD/USB player, Digital video player/USB/SD player can be remotely operated.
Tripod stand mountable with ST-40/Wall mountable with SR-40.
Optional carrying bag (SB-21).
Portable amplifier: PA-505R
Focus speaker: SP-505
Model Focus 505
Output power 50W, 30W(RMS) 4Ω load (class-D)
Speaker system 6 ½" full range
Audio input Mic in, Aux in
Audio output Aux out, External speaker
T.H.D. < 0.5%
Freq. response 50Hz-20KHz ± 3dB
Antenna Built-in
Power supply 100-240V AC / 15V DC, 4.3A
Battery type Lead-Acid
Battery spec 12V, 2.9A
Battery Q'ty 1
Operating time 5-6 hrs in music, 10-12 hrs in speech
Charging time about 4 hrs
Dimension (mm) 313(H) x 220(W) x 215(D)
Weight (kg) 4.8
100-channel receiver module SDR-5200M IrDA,SDR-5100M IrDA
100-channel transmitter module RP-5100M
MP3+Bluetooth module DPRB-500M
Patent Taiwan, China, USA, Germany
Approval CE, RoHS, FCC, ICID
*Specifications subject to change without notice.
