audiowerkstatt midi-clock-divider v2

The audiowerkstatt midi-clock-divider v2 is a clock-divider for the MIDI-clock.

The audiowerkstatt midi-clock-divider v2 divides the MIDI-clock of the MIDI-master, whereby the MIDI-slave runs correspondingly slower. The division-ratios are 1/1, 1/2, 1/3, ..., 1/8, 1/9.

If the division-factor 1/1 is selected, the MIDI-clock is simply passed through. With the division-factor of 1/2 the MIDI-slave runs at half the speed. So 16ths-notes will be 8th-notes and the loop is twice as long.

Very useful to double the loop length of the MIDI-slave (eg MIDI-sequencer or [audio-]looper). When using the division-factor 1/8 and an originally one bar long loop runs over 8 bars.

And good for experimental musicians, especially if an odd division-factor is selected and MIDI-master and slave seem to be not in sync, but from time to time come together in perfect sync.

You can also set whether only the newly created MIDI-clock and mmc commands (start, stop, continue) are sent or the, at the MIDI-in incoming data, will be mixed with that.

All settings will be saved and restored at startup.

Details can be found in the manual.

Connectors: MIDI in (5-pol din)MIDI out (5-pol din)Power (plug 5,5mm, pin 2,1mm)(Power-Supply-Unit not included!)
Power: 9-12V AC or DC (polarity doesn´t matter)
Dimensions: 112mm x 72mm x 48mm
Weight: 260g
