The Twin Waves MKII evolution brings a redesigned layout, additional knobs for more hands-on fun and semi-modular cross-patching between sections. All of the original features are present in 8HP: a top selection of synthesis techniques, each with their key parameter directly at hand, enriched by a full set of complementary features. More than ever the Twin Waves is versatility at its best.

  • Two oscillators independently set as VCO, LFO or random
  • Features in VCO mode:
  • V/Oct tracking over 10 octaves
  • Through zero and linear FM
  • Sub-octave output
  • Hard & soft synchronization
  • VCA control and CV algorithm selection
  • Quantizer with various scales

  • Algorithm-based synthesis to choose among:

  • Wave shaping
  • Phase modulation
  • Phase positioning of multiple waves
  • 5 stacked oscillators with unison detune
  • Self-sync with phantom oscillator
  • Additive synthesis (7 waves)
  • Variable bit reduction (bit-crushing)
  • Ring modulator with its own 2nd oscillator
  • Noise with LPF, BPF, or resonant VCFs

  • Features in LFO mode:

  • Simultaneous signal and cycle trigger outputs
  • External wave synchronization/restart
  • Clock controlled rate with CV multiplier and divider
  • CV and knob control of output level
  • Algorithm based wave engine with a selection of:
  • Wave shaping
  • Phase modulation
  • Random levels and vectors (also Brownian)
  • Randomly spaced/warped triggers and waves

  • Display with contextual icons and instant reminder help text

  • LEDs indicating potentiometer vs. value matching, switch settings and output signals
  • Automatically saved settings for instant recall at power on
  • Firmware update via a simple audio file Fundamental frequency range in VCO mode: 10Hz to 10KHz = over 10 octaves VCO audio range (incl. harmonics): DC to 20KHz LFO frequency range (internal / external clocking): 2 minutes to 2KHz / several days to 2KHz Input and output conversion: 16-bit ADCs, 24-bit 96KHz DACs

Found Sound Australia Pty Ltd.
110 Albert St
Brunswick East, VIC 3057

ConditionBrand New (New)
Brand New items are sold by an authorized dealer or original builder and include all original packaging.learn more
  • Twin Waves MK II
  • Silver
  • 2020
Made In
  • Belgium
