Nuprime IDA-6 Integrated Amplifier (Black)

The NuPrime IDA-6 Integrated Amplifier
Class A+D Integrated Amplifier with DAC

The NuPrime IDA-6 consists of an integrated amplifier and a digital-to-analog converter that decodes PCM 384 and DoP64. The IDA-6 provides the convenience of wireless audio in a small, handsomely designed home stereo component. NuPrime's Single End Class A+D hybrid amplification technologies deliver the substance and warmth of Class A amplification and the efficiency and speed of Class D technology. The spacious, transparent, dynamic and luxuriously textured soundstage has to be heard to believed.

Ultra-low Jitter and Ultra-low Distortion Decoding

NuPrime's IDA-6 utilizes a design technique that allows it to perform PCM 384 and DoP64 decoding that measured up to the performance of a high-end DAC. A SRC (Sampling Rate Converter) FPGA IC chip upsamples the input signal to gigahertz range before it is down sampled to a fixed PCM sampling rate for ultra-low jitter and distortion rates. The result is sound quality that is virtually unprecedented for an integrated amp at this price point.

Shortest Possible Signal Paths

With all its stages in a single chassis, the IDA-6 avails itself of the shortest possible signal paths for a black-velvet background to your music. Volume changes are available in 99 precise 0.5dB increments for each input. Precise level matching is a breeze, as is your ability to make comparisons of different music sources, thanks to onboard memory retention of set levels for each source.

Innovative Implementation of Class-D Design

The NuPrime amp circuit improves on traditional Class-D design by using a self-oscillating circuit to generate pulse-width modulation. The amplifier switches at a frequency of 500 kHz, well beyond the compact disc’s 44.1 kHz sampling rate. Most Class-D amps switch at 300 kHz or lower. In addition, a new low noise switching power supply is designed specifically to complement the IDA-6 amplifier.

Five digital inputs and one analog stereo input offer complete system flexibility. Asynchronous transfer mode provides very low jitter. An extension port accommodates the included Bluetooth aptX dongle or an optional WiFi dongle (sold separately) for wireless music streaming.

The IDA-6 has very low power consumption while in Standby Mode. A convenient wireless remote control is included.

The Emotional Experience

The IDA-6's frequency response to 50 kHz elevates vocals into emotional experiences. Similarly, instrumental upper registers mimic a live performance’s shimmering heights. The IDA-6's features and specifications have few equals. Just one audition will convince you that the performance is unmatched for this level of audiophile gear.

• Single End Class A + D design achieves audiophile-quality sound with Class-D’s dynamics, speed and efficiency
• Sampling Rate Converter (SRC) IC + DAC supporting PCM 384 and DoP64 decoding, that also decodes DoP formats via coaxial and optical inputs
• Extension port a accommodates the included Bluetooth aptX dongle or an optional WiFi dongle (sold separately) for wireless music streaming
• Full microprocessor control with memory retention for each input volume
• Five digital inputs and one analog stereo input for complete system flexibility
• Capable of decoding DoP formats via coaxial and optical inputs
• Volume adjustment in 99 precise 0.5dB increments
• Advanced switched-resistor ladder network (implemented in FPGA) for controlling volume, with a single resistor in the signal path at any volume setting
• Exclusive driver software for Windows; Standard driver software for Mac
• Asynchronous transfer mode
• Very low power consumption on Standby Mode
• Includes wireless remote control

Inputs

• 3.5mm Analog Input
• Extension port for optional modules: NuPrime BTR-8 (Bluetooth aptX) or NuPrime WR-100 (WiFi receiver)
• Optical Digital S/PDIF (PCM up to 192K supporting DoP format DSD64)
• Optical Digital S/PDIF (PCM up to 192K supporting DoP format DSD64)
• Coaxial Digital S/PDIF (PCM up to 384K supporting DoP format DSD64)
• Coaxial Digital S/PDIF (PCM up to 384K supporting DoP format DSD64)

Outputs

• 2 x pair of stereo speaker (binding posts) output

Sampling Rates

• Optical Sampling Rates: 44.1KHz, 48KHz, 88.2KHz, 96, 176.4KHz, 192KHz
• Coaxial Sampling Rates: 44.1KHz, 48KHz, 88.2KHz, 96, 176.4KHz, 192KHz, 352.8KHZ, 384KHz
• Bit Resolution: 24-bits

• Power output: 60W x 2 (8-Ohm) or 35W x 4 (4-Ohm)
• THD+N: 0.05%
• SNR: 88dB
• Peak Output Power: 170W
• Frequency Response: 10Hz ~50KHz
• Dimensions: 7.87" W x 2.4" H (including feet) x 7.8" D
• Weight: 3.0 lbs.
