Rane SM 26B

This is ideal for a group/band that is recording - it allows you to hear exactly what you want to hear in your headphones as everyone is playing and you are recording...

The Rane Model SM 26B Splitter Mixer is one of the most useful, yet unusual audio products available.

In its most basic configuration, it is a six-to-two line level mixer. It will accept six balanced or unbalanced line level inputs which are applied to six Level and Pan controls. An additional stereo Master Input allows a total of eight inputs.

The result of the mix is sent to an overall Master Output Level control and appears at the Left and Right Output jacks on the rear. In its splitter mode, the SM 26B can take one or two line level inputs and split these to any of the six Mono Outputs on the rear.

The Mix/Pan controls in this mode control the level from each of the two input buses to be applied to each Output. Internal header blocks allow the Mix Output jacks to become an independent stereo out, allowing a total of eight outputs. The SM 26B may also be used as a six input, six output buffer amplifier in which case signal applied to Input 1 is delivered to Output 1, and so on.
