Santa Fe Springs, CA, United States
About this listing
Recommended for professional audio mid-range applications in a sealed cabinet, or as a mid-bass in a vented satellite enclosure.speaker_size: 8Basket Diameter in: 8Basket Diameter_mm: 203Nominal Impedance: 8Power Rating_Watts: 125Power Rating_Music Program: 250Resonance: 73Freq Range HZ: 58Freq Range kHZ: 5Sensitivity dB: 94Mag Wt_oz: 20Gap Height_in: 0.25Gap Height_mm: 6.4Voice Coil_Diam_in: 1.5Voice Coil Dia_mm: 38fs: 73Re: 5.3Le: 0.44Qms: 4.6Qes: 0.68Qts: 0.59Vas_ltr: 17.7Vas_cuft: 0.63VD: 67Cms: 0.28BL: 7.8Mms: 17EBP: 107Xmax: 3.2Sd: 210Xlim: 7.1Enc Recom Sealed: ACCEPTABLERec Enc Volume_Sealed Min_liters: 5Rec Enc Volume_Sealed Max_liters: 7Rec Enc Volume_Sealed Min_cuft: 0.18Rec Enc Volume_Sealed Max_cuft: 0.25Enc Recom Vented: ACCEPTABLERec Enc Volume_Vented Min_liters: 16.7Rec Enc Volume_Vented Max_liters: 25.5Rec Enc Volume_Vented Min_cuft: 0.59Rec Enc Volume_Vented Max_cuft: 0.9Drive Volume Displaced_liters: 0.58Driver Volume Displaced_cuft: 0.02Overall_Diam_in: 8.24Overall_Diam_mm: 209.3Baffle Hole_Diam_in: 7.13Baffle Hole_Diam_mm: 181.1Front Seal Gask: YesRear Seal Gask: YesMounting Holes_Diam_in: 0.22Mounting Holes_Diam_mm: 5.6Mounting Holes_BCD_in: 7.75Mounting Holes_BCD_mm: 196.9Depth_in: 3.25Depth_mm: 82.6Net Weight_lbs: 4.3Net Weight_kg: 1.95Ship Weight_lbs: 5.1Ship Weight_kg: 2.31Coil Construction: Copper voice coilCoil Former: Polyimide formerMagnet Comp: Ferrite magnetCore Details: Vented coreBasket Material: Pressed steel basketCone Composition: Paper coneCone Edge Composition: Cloth cone edgeDust Cap Composition: Solid composition paper dust capcoloration: Genre: Model Group: American StandardSubwoofer Usage: Woofer Usage: YesMidBass Usage: YesMidrange Usage: YesBass Guitar: YesClosed box: YesReflex Box: YesScoop Loading: Horn Loading:
Price$79.99
Free Shipping
Free Shipping
from Santa Fe Springs, CA
14-Day Return Policy
Enjoy peace of mind with your new gear
1
4 in stock
