- Thunderbolt Interface
- Design: Rack Enclosures
- Thunderbolt: Thunderbolt 3
- Supported Operating Systems: macOS 10.14 (and later), Windows 10 (and later)
- Input channels that can be used simultaneously: 18
- Mic-In: 4x XLR (Ch 1-4)
- Line in: 8x 6,3 mm Jack (Ch 1-8)
- Hi-Z Input: 2x 6,3 mm Jack (Ch 1-2)
- Headphone Output: 2x 6,3 mm Stereo Jack
- Line out: 10x 6,3 mm Jack (balanced)
- ADAT-In: Yes, 2 (up to 8 Mono Channels)
- ADAT-Out: Yes, 2 (up to 8 Mono Channels)
- S/PDIF Coaxial I/O: yes
- BNC Word Clock: 1 In / 1 Out
- Direct Monitoring: Yes (Software)
- Onboard Effects: ja, digital
- Displays: LEDs
- Sampling Rate: 192 kHz
- Resolution: 24-Bits
- Dynamic Range: 129 dB
- USB: no
- Power Supply: External Power Adapter
- Rack mounting: 19"/1U
- combinable with up to 4 Apollos with Thunderbolt and a total of six UAD-2 devices
- with 6 SHARC DSP for UAD-2 plug-ins (also usable in DAW)
- Unison Technology
- Includes: Interface, Power Supply, Software
Condition | Brand New (New) Brand New items are sold by an authorized dealer or original builder and include all original packaging.Learn more |
Brand | |
Model |
|
Categories | |
Sample Rate |
|
Bus-Powered |
|
Electronics |
|
Digital Output Format |
|
Compatibility |
|
Digital Input Format |
|
Bit Depth |
|
Computer Connectivity |
|
Format |
|
Number of Mic Preamps |
|
Number of Analog Outputs |
|
Number of Analog Inputs |
|
