ACS 4x2 - Amp Cab Selector

4x Guitar Amplifier 2x Cabinet/Load Switcher, made by KHE Audio in Switzerland.

Instantly switch between all your guitars amp heads, speaker cabinets and load boxes, by the single push of a button, without interrupting your workflow! instant A/B testing and amp shootouts - no more creative interruptions!

The KHE ACS Series is the most advanced guitar amp switching system on the market:
✔ switch while you play - no need to put amps into standby or stop playing
✔ 100% safe for tube amps - load resistors & load detection
✔ no amp can be activated if no load is active
✔ MIDI control
✔ fx-loop switching
✔ global power attenuator insert loop
✔ modular system - multiple switchers can be linked
✔ works with tube & solid-state amps, speaker cabinets & load boxes, heads & combos
✔ pedal & reamping-friendly design
✔ low noise, no hum, transparent sound, fast & click-less switching
✔ analog relay switching, digitally controlled by a microcontroller

The KHE ACS-Series consists of 7 amp switcher models with different sizes and switching options to help you find the perfect switching system for your setup! (single configurations: 4x2, 4x4, 8x4, 8x1, 1x8)
All rack switchers can be linked and daisy-chained to expand & grow the switching system with your amp collection! (combination examples: 8x8,12x4, 12x8, 16x4, 16x8, 16x16, 24x8 etc)

ACS 4x2 - Features

The KHE ACS 4x2 is the smallest amp switcher in our line-up. Compact and robust design coupled with the most essential features:

• Amp Switching - switch between 4 guitar amps (one at the time/mono). works with tube & solid-state amps, heads and combos.
• Cab & Load Switching - switch between 2 speaker cabinets or load boxes
• Dual-Cab Mode - activate and play two Speaker Cabinets or Loadboxes in parallel at the same time.
• MIDI Control - remotely control your amp collection via MIDI by pedal boards or other MIDI controllers
• Ground Lift, Tuner Output, Front & Rear Guitar Input
• Load Resistors + Load Detection
• desktop style enclosure, 2,5kg, external 15VDC PSU

Compatibility
The KHE ACS is compatible with all types of amplifiers and load devices, such as tube amps, solid-state amps, speaker cabinets, load boxes and power attenuators, up to 150 watts per channel.

Safety Features
The ACS is 100% safe for tube amplifiers: Load resistors protect the unused amplifiers and a load detection circuit supervises the cabinet jacks for the presence of a load device. If no load is connected, the cabinet outputs are automatically locked and excluded from the switching operation. This ensures amplifiers can never be activated without a real load connected.

✔ 150 Watts power handling per channel
✔ built like a tank with colour-coded jacks
✔ low noise, no hum, transparent sound, fast & click-less switching
✔ analog relay switching, digitally controlled by a microcontroller
✔ most advanced amp switcher on the market!
✔ 2 years warranty
✔ highest quality built in Switzerland

Remove the guess-work when searching the perfect amp and tone. Get perspective by comparing amps side-by-side instantly. Discover new gear combinations and possibilities and start using amps again that have been sitting around for a long time!

KHE ACS-Series - Product Line-Up

• ACS 4x2 - 4 Amplifiers, 2 Cabinets - Compact desk-style amp-cab-switcher aimed for smaller setups
• ACS 4x4 - 4 Amplifiers, 4 Cabinets - 19" 1U amp-cab-switcher for medium-sized setups
• ACS 4x4 FX - 4 Amps, 4 Cabs, 4 switchable FX-Loops - Identical to the 4x4 plus fx-loop switching
• ACS 8x4 - 8 Amplifiers, 4 Cabinets - 19" 1U rack size for larger amp cab setups
• ASX 8 - 8 Amps, 1 Cab - Standalone Amp-Switcher, or to expand other switchers with 8 Amps
• CSX 8 - 1 Amplifier, 8 Cabinets - Standalone Cab-Switcher, or to expand other switchers with 8 Cabs
• AFX 8 - 8 switchable FX-Loops - FX-Loop Switching unit as an add-on for the ACS 8x4 and the ASX 8
